Explore EX30 specifications
Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.
Platform
Platform
- Fuel Type
- Electric
- Driveline
- RWD
- Transmission
- Automatic
- Number of seats
- 5
- Weight (Running Order Mass)
- 1 850 kg
- Trailer max weight
- 1 600 kg
- Roof load max weight
- 75 kg
Performance
- Electric Range
- Up to 540 km
- Electric energy consumption combined (NEDC)
- 14.5 kWh/100km
- Power
- 200 kW / 272 hp
- Max torque
- 343 Nm
- 0-100 km/h
- 5.3 s
- Top speed
- 180 km/h
Charging
- Battery energy (nominal)
- 69 kWh
- Battery charging duration 0-100% (3-phase 16A)
- 8 h
- Battery charging duration 10-80% (DC 175kW)
- 28 m
- Fuel Type
- Electric
- Driveline
- AWD
- Transmission
- Automatic
- Number of seats
- 5
- Weight (Running Order Mass)
- 1 960 kg
- Trailer max weight
- 1 600 kg
- Roof load max weight
- 75 kg
- Electric Range
- Up to 490 km
- Electric energy consumption combined (NEDC)
- 16.3 kWh/100km
- Power
- 315 kW / 428 hp
- Max torque
- 543 Nm
- 0-100 km/h
- 3.7 s
- Top speed
- 180 km/h
- Battery energy (nominal)
- 69 kWh
- Battery charging duration 0-100% (3-phase 16A)
- 8 h
- Battery charging duration 10-80% (DC 350kW)
- 28 m
Features and upgrades
Equipment level
Category
Not included
Optional
Included
Will it fit?
Car dimensions
Exterior
- Vehicle height at kerb weight with one person
- 1 549 mm
- Width (mirrors incl)
- 2 032 mm
- Front track width
- 1 590 mm
- Width
- 1 837 mm
- Width (mirrors folded)
- 1 940 mm
- Rear track width
- 1 595 mm
- Vehicle length
- 4 233 mm
- Wheel base
- 2 650 mm
- Turning circle
- 11 m
Interior
- Max head room front
- 1 058 mm
- Shoulder room rear
- 1 346 mm
- Hip room front
- 1 379 mm
- Head room rear
- 974 mm
- Leg room front
- 1 063 mm
- Hip room rear
- 1 175 mm
- Shoulder room front
- 1 400 mm
- Leg room rear
- 821 mm
Storage
- Cargo floor width between wheel housing
- 994 mm
- Second seatback to tailgate - top of second seatback
- 566 mm
- First seatback to tailgate - top of first seatback
- 1 355 mm
- Cargo capacity (max) - second row up
- 400 L
- Cargo capacity (max) - rows folded
- 1 000 L
- Cargo capacity (front)
- 7 L
