Symbols and messages for Pilot Assist*1

A number of symbols and messages regarding Pilot Assist can be shown via the driver display and/or the head-up display*.

P5-1617-PilotAssist2 Symbol Steering Standby
Grey steering wheel symbolIndicates deactivated steering assistance. When Pilot Assist provides steering assistance, the steering wheel is green.
P6-1817-PA-Symbol Hands-on-Steeringwheel
Symbol for hands on the steering wheelThe system cannot detect whether the driver has his/her hands on the steering wheel. Place your hands on the steering wheel and actively steer the car.
P5-1946-Owners manual symbol

Windscreen sensor

Sensor blocked, see Owner's manual

Clean the windscreen in front of the camera and radar unit's detectors.

A text message can be cleared by briefly pressing the P5–1507–Symbol-OK button button, located in the centre of the steering wheel's right-hand keypad.

If a message remains: Contact a workshop – an authorised Volvo workshop is recommended.

  1. * Option/accessory.
  2. 1 This function can be either standard or optional, depending on market.
