Symbols and messages for lane assistance

A number of symbols and messages regarding lane assistance (LKA1) can be shown on the driver display. Here are some examples.
P5-1946-Owners manual symbol

Driver support system

Reduced functionality Service required

The system does not function as it should. A workshop should be contacted2.
P5-1946-Owners manual symbol

Windscreen sensor

Sensor blocked, see Owner's manual

The ability of the camera to scan the roadway in front of the car is reduced.
P5-1846-Lane Keeping Aid symbol

Lane Keeping Aid

Apply steering

The LKA steering assistance does not function if the driver does not have his/her hands on the steering wheel. Follow the instruction and steer the car.
P5-1846-Lane Keeping Aid symbol with orange border

Lane Keeping Aid

Standby until steering applied

LKA is set in standby mode until the driver starts to steer the car again.

A text message can be cleared by briefly pressing the P5–1507–Symbol-OK button button, located in the centre of the steering wheel's right-hand keypad.

If a message persists, contact a workshop2.

  1. 1 Lane Keeping Aid
  2. 2 An authorised Volvo workshop is recommended.
