Explore EX30 specifications

Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.

Side view of the fully electric Volvo EX30 with open hood, doors, and trunk.

Platform

Single Motor Extended Range

Platform

Fuel Type
Electric
Driveline
RWD
Transmission
Automatic
Number of seats
5
Trailer max weight
907 kg
Roof load max weight
75 kg

Performance

Electric Range
Up to 420 km
Max engine power (hp)
268 hp
Max torque
253 lb.-ft.
0-100 km/h
5.3 s
Top speed
180 km/h

Charging

Battery energy (nominal)
69.0 kWh
Battery charging duration 0-100%

Battery charging duration 0-100%

Typical time to charge from 0 to 100% with 11kW AC-fast charging (Level 2) Single phase 45A.

8 h
Battery charging duration 10-80% (DC 153kW)
26.5 m

Twin Motor Performance



Fuel Type
Electric
Driveline
AWD
Transmission
Automatic
Number of seats
5
Trailer max weight
907 kg
Roof load max weight
75 kg



Electric Range
Up to 407 km
Max engine power (hp)
422 hp
Max torque
400 lb.-ft.
0-100 km/h
3.6 s
Top speed
180 km/h



Battery energy (nominal)
69.0 kWh
Battery charging duration 0-100%

Battery charging duration 0-100%

Typical time to charge from 0 to 100% with 11kW AC-fast charging (Level 2) Single phase 45A.

8 h
Battery charging duration 10-80% (DC 153kW)
26.5 m

Features and upgrades

package level

Category

  • Not included

  • Optional

  • Included

Will it fit?

See how these items fit in the trunk
Stroller
Golf bag
Dresser

Car dimensions

Exterior

Height
1 555 mm
Width (mirrors incl)
2 032 mm
Front track width
1 590 mm
Width
1 838 mm
Rear track width
1 595 mm
Vehicle length
4 233 mm
Wheel base
2 650 mm
Turning circle
10.7 m

Interior

Max head room front
1 058 mm
Shoulder room rear
1 346 mm
Hip room front
1 379 mm
Head room rear
974 mm
Leg room front
1 063 mm
Hip room rear
1 175 mm
Shoulder room front
1 400 mm
Leg room rear
821 mm

Storage

Cargo floor width between wheel housing
994 mm
Second seatback to tailgate - top of second seatback
566 mm
First seatback to tailgate - top of first seatback
1 355 mm
Cargo capacity (max) - second row up
400 l
Cargo capacity (max) - rear row(s) folded
1 000 l
Cargo capacity (front)
7 l

Features depicted may not be standard or available for all markets, package levels and powertrain options. European specifications shown. Google services are enabled through a digital services package that is included for four years. After this period, new terms and fees will apply if you choose to renew. Google, Google Maps and Google Play are trademarks of Google LLC.
