Lidar is no longer available for EX90.

Explore EX90 specifications

Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.

Side view of the Volvo EX90 with open hood, doors, and trunk in a white studio environment.

Platform

Twin Motor Performance

Platform

Fuel Type
Electric
Driveline
AWD
Transmission
Automatic
Number of seats
6 - 7
Weight (Max Laden Mass)
3390 kg
Trailer max weight
2 200 kg

Performance

Electric range (up to)

Electric range (up to)

Volvo EX90 Twin Motor Extended Performance, 370kW (510 hp), 21” Wheels: combined power consumption 24.9 kWh/100 km, electric range: combined up to 499 km. 20” or 22” Wheels: combined power consumption 26.1 kWh/100 km, electric range: combined up to 483 km. The figures are based upon Natural Resources Canada (NRCan) approved test cycles. The actual range, the actual energy consumption and the charging times depend on various factors, such as the outside temperature, the current battery temperature, the charging device and other external factors as well as the condition of the batteries and vehicle. See https://fcr-ccc.nrcan-rncan.gc.ca/en for more information.

Up to 499 km
Max engine power (hp)

Max engine power (hp)

Power figures derive from estimates and calculations performed by Volvo Cars for the Volvo EX90. These outcomes are not guaranteed.

510 hp
Max torque
671 lb-ft
0-100 km/h

0-100 km/h

Acceleration time is based on the specified powertrain. Real-world results will vary depending on various factors, including weather and road conditions, tires and the car's weight.

4.9 s
Top speed
180 km/h

Charging

Battery energy (nominal)
111 kWh
Battery charging duration 0-100%

Battery charging duration 0-100%

Typical time to charge from 0 to 100% with 11kW AC fast charging (Level 2) single-phase 48A.

10 h
Battery charging duration 10-80% (DC 250kW)

Battery charging duration 10-80% (DC 250kW)

This figure is the typical time to charge from 10 to 80% at a 250kW DC fast charging station. Figures are preliminary and derived from estimates and calculations performed for the Volvo EX90. These outcomes are not guaranteed. Charging times can vary and depend on factors such as outdoor temperature, battery temperature, charging equipment, battery condition and car condition.

30 m

Car dimensions []

Exterior

Height
1 744 mm
Width (mirrors incl)
2 113 mm
Front track width
1 673 mm
Width
1 964 mm
Rear track width
1 667 mm
Vehicle length
5 037 mm
Wheel base
2 985 mm
Turning Circle
11.8 m

Interior

Head room front with panoramic roof
1 075 mm
Shoulder room rear
1 467 mm
Hip room front
1 422 mm
Head room rear with panoramic roof
1 056 mm
Leg room front
1 039 mm
Hip room rear
1 434 mm
Shoulder room front
1 475 mm
Leg room rear
926 mm

Storage - 6 Seats

Cargo floor width between wheel housing
1 130 mm
Second seatback to tailgate - top of second seatback
1 101 mm
First seatback to tailgate - top of first seatback
1 909 mm
Cargo capacity - third row up
324 l
Cargo capacity - second row up
690 l
Cargo capacity - rear row(s) folded
1 212 l
Cargo capacity (max) - third row up
377 l
Cargo capacity (max) - second row up
1 045 l
Cargo capacity (max) - rear row(s) folded
2 082 l
Cargo capacity (front)
46 l

Storage - 7 Seats

Cargo floor width between wheel housing
1 130 mm
Second seatback to tailgate - top of second seatback
1 090 mm
First seatback to tailgate - top of first seatback
1 909 mm
Cargo capacity - third row up
324 l
Cargo capacity - second row up
697 l
Cargo capacity - rear row(s) folded
1 316 l
Cargo capacity (max) - third row up
384 l
Cargo capacity (max) - second row up
1 057 l
Cargo capacity (max) - rear row(s) folded
2 135 l
Cargo capacity (front)
46 l

Track width may differ depending on wheel size.

Features

Category

  • Not included

  • Optional

  • Included

Charging

11kW On-Board Charger (OBC)

      Climate

      Air purifier and remote cabin pre-cleaning

          Electric cabin heater and cooler

              Four-zone climate system

                  Heat pump

                      Heated steering wheel

                          Humidity sensor

                              Third row air conditioning

                                  Wiper blades with integrated washers

                                      Drivers support

                                      14.5-inch centre display

                                          360° camera with 3D view

                                              9-inch driver display

                                                  Active air suspension

                                                      Active chassis

                                                          Advanced sensing technology

                                                              Auto-dimmed rear view mirrors

                                                                  BLIS™ (Blind Spot Information System)

                                                                      Chassis

                                                                          Collision avoidance and mitigation

                                                                              Connected Safety

                                                                                  Core computing

                                                                                      Door opening alert

                                                                                          Driver Understanding

                                                                                              Head-up display

                                                                                                  Headlight cleaning

                                                                                                      Intersection autobrake

                                                                                                          LED headlights

                                                                                                              Occupant sensing

                                                                                                                  Park Pilot Assist

                                                                                                                      Pedestrian, cyclist and scooter steering avoidance

                                                                                                                          Pilot Assist

                                                                                                                              Power adjustable steering column

                                                                                                                                  Rain sensor

                                                                                                                                      Rear cross traffic alert with low speed auto brake

                                                                                                                                          Road sign Information

                                                                                                                                              Run-off road Mitigation

                                                                                                                                                  Volvo Assistance

                                                                                                                                                      Exterior

                                                                                                                                                      Body-coloured door handles

                                                                                                                                                          20-inch 5-spoke aero

                                                                                                                                                              20-inch 5-spoke aero, rear

                                                                                                                                                                  21-inch 8-spoke aero

                                                                                                                                                                      21-inch 8-spoke aero, rear

                                                                                                                                                                          22-inch 5-spoke aero

                                                                                                                                                                              22-inch 5-spoke aero, rear

                                                                                                                                                                                  All-season Tires

                                                                                                                                                                                      All-season Tires

                                                                                                                                                                                          All-season Tires

                                                                                                                                                                                              Body-coloured covered grille

                                                                                                                                                                                                  Door mirror covers, high-gloss black

                                                                                                                                                                                                      Flush door handles with ground lighting

                                                                                                                                                                                                          High-gloss black side window trim

                                                                                                                                                                                                              Lower door mouldings, High-gloss Black

                                                                                                                                                                                                                  Panoramic roof, fixed

                                                                                                                                                                                                                      Roof rails, glossy black

                                                                                                                                                                                                                          Tinted rear windows

                                                                                                                                                                                                                              Interior

                                                                                                                                                                                                                              Birch decor

                                                                                                                                                                                                                                  Charcoal headlining

                                                                                                                                                                                                                                      Dawn headlining

                                                                                                                                                                                                                                          Interior illumination, high level

                                                                                                                                                                                                                                              Jewel-design air intake controls

                                                                                                                                                                                                                                                  Jewel-design media rotary knob

                                                                                                                                                                                                                                                      Light Ash decor

                                                                                                                                                                                                                                                          Nordico upholstery

                                                                                                                                                                                                                                                              Nordico upholstery with ventilation

                                                                                                                                                                                                                                                                  Premium textile interior cabin floor mats

                                                                                                                                                                                                                                                                      Tailored dashboard and door panels

                                                                                                                                                                                                                                                                          Tailored steering wheel

                                                                                                                                                                                                                                                                              Tailored wool blend upholstery

                                                                                                                                                                                                                                                                                  Pack & Load

                                                                                                                                                                                                                                                                                  Front load compartment

                                                                                                                                                                                                                                                                                      Power tailgate

                                                                                                                                                                                                                                                                                          Performance

                                                                                                                                                                                                                                                                                          Shift-by-wire single speed transmission

                                                                                                                                                                                                                                                                                              Safety & Security

                                                                                                                                                                                                                                                                                              Alarm

                                                                                                                                                                                                                                                                                                  Central locking with power release and soft close

                                                                                                                                                                                                                                                                                                      Digital key plus

                                                                                                                                                                                                                                                                                                          Inflatable Curtain

                                                                                                                                                                                                                                                                                                              Integrated booster cushion

                                                                                                                                                                                                                                                                                                                  ISOFIX mounting points, rear seat

                                                                                                                                                                                                                                                                                                                      Key card

                                                                                                                                                                                                                                                                                                                          Knee airbags, driver and front passenger

                                                                                                                                                                                                                                                                                                                              Laminated side and rear windows

                                                                                                                                                                                                                                                                                                                                  Occupant Weight Sensor

                                                                                                                                                                                                                                                                                                                                      Safety belts

                                                                                                                                                                                                                                                                                                                                          Side impact protection

                                                                                                                                                                                                                                                                                                                                              Tempered side and rear windows

                                                                                                                                                                                                                                                                                                                                                  Temporary mobility kit

                                                                                                                                                                                                                                                                                                                                                      Whiplash injury protection

                                                                                                                                                                                                                                                                                                                                                          Seats

                                                                                                                                                                                                                                                                                                                                                          6 seats

                                                                                                                                                                                                                                                                                                                                                              7 seats

                                                                                                                                                                                                                                                                                                                                                                  Front seat massage

                                                                                                                                                                                                                                                                                                                                                                      Heated rear seats

                                                                                                                                                                                                                                                                                                                                                                          Manual cushion extensions, driver and passenger

                                                                                                                                                                                                                                                                                                                                                                              Power 4-way lumbar support

                                                                                                                                                                                                                                                                                                                                                                                  Power driver seat with memory

                                                                                                                                                                                                                                                                                                                                                                                      Power passenger seat

                                                                                                                                                                                                                                                                                                                                                                                          Power side bolsters

                                                                                                                                                                                                                                                                                                                                                                                              Ventilated seats

                                                                                                                                                                                                                                                                                                                                                                                                  Tech & Sound

                                                                                                                                                                                                                                                                                                                                                                                                  5G capability

                                                                                                                                                                                                                                                                                                                                                                                                      Bluetooth® connection

                                                                                                                                                                                                                                                                                                                                                                                                          Bose Premium Sound system

                                                                                                                                                                                                                                                                                                                                                                                                              Bowers & Wilkins High Fidelity audio system

                                                                                                                                                                                                                                                                                                                                                                                                                  Google built-in

                                                                                                                                                                                                                                                                                                                                                                                                                      In-car communication

                                                                                                                                                                                                                                                                                                                                                                                                                          Over-the-air updates (OTA)

                                                                                                                                                                                                                                                                                                                                                                                                                              SiriusXM Satellite Radio

                                                                                                                                                                                                                                                                                                                                                                                                                                  USB-C ports

                                                                                                                                                                                                                                                                                                                                                                                                                                      Volvo Cars app

                                                                                                                                                                                                                                                                                                                                                                                                                                          Wireless Apple CarPlay

                                                                                                                                                                                                                                                                                                                                                                                                                                              Wireless phone charging

                                                                                                                                                                                                                                                                                                                                                                                                                                                  Shopping tools

                                                                                                                                                                                                                                                                                                                                                                                                                                                  Compare models
                                                                                                                                                                                                                                                                                                                                                                                                                                                  View special offers
                                                                                                                                                                                                                                                                                                                                                                                                                                                  Book a test drive
                                                                                                                                                                                                                                                                                                                                                                                                                                                  Contact your retailer

                                                                                                                                                                                                                                                                                                                                                                                                                                                  The availability of the features and services mentioned above may not be guaranteed when customers take delivery of their EX90. Potentially missing features and services will be released remotely over-the-air while some may require a dealership visit. Features may not be available in all markets and will not be standard in all markets or for all models. European specifications shown.

                                                                                                                                                                                                                                                                                                                                                                                                                                                  Google services are enabled through a digital services package that is included for four years. After this period, new terms and fees will apply if you choose to renew. Google, Google Maps and Google Play are trademarks of Google LLC.
