Explore XC90 specifications

Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.

Side view of the Volvo XC90 with open hood, doors, and trunk in a white studio environment.

Platform

T8 AWD Plug-in hybrid

Platform

Fuel Type
Electric/Gas
Driveline
AWD
Transmission
Automatic
Number of seats
6 - 7
Weight (Max Laden Mass)
2950 kg
Trailer max weight
2 400 kg
Roof load max weight
100 kg

Performance

Electric range (up to)

Electric range (up to)

The figures are based upon Natural Resources Canada (NRCan) approved test cycles. The actual range, the actual energy consumption and the charging times depend on various factors, such as the outside temperature, the current battery temperature, the charging device and other external factors as well as the condition of the batteries and vehicle. See https://fcr-ccc.nrcan-rncan.gc.ca/en for more information.

Up to 53 km
Fuel Consumption (Combined)

Fuel Consumption (Combined)

The figures are based upon Natural Resources Canada (NRCan) approved test cycles. The actual range, the actual energy consumption and the charging times depend on various factors, such as the outside temperature, the current battery temperature, the charging device and other external factors as well as the condition of the batteries and vehicle. See https://fcr-ccc.nrcan-rncan.gc.ca/en for more information​.

8.9 l/100km
Fuel Capacity
71 l
Max engine power (hp)

Max engine power (hp)

Power figures derive from estimates and calculations performed by Volvo Cars for the Volvo XC90. These outcomes are not guaranteed.

401 hp
Max torque
494 lb-ft
0-100 km/h

0-100 km/h

Acceleration time is based on the specified powertrain. Real-world results will vary depending on various factors, including weather and road conditions, tires and the car's weight.​

5.4 s
Top speed
180 km/h

Charging

Battery energy (nominal)
19 kWh
Battery charging duration 0-100%

Battery charging duration 0-100%

Typical time to charge from 0 to 100% with AC fast charging (Level 2) single-phase 16A.

5 h

Car dimensions []

Exterior

Height
1 771 mm
Width (mirrors incl)
2 140 mm
Front track width
1 673 mm
Width
1 931 mm
Rear track width
1 675 mm
Vehicle length
4 953 mm
Wheel base
2 984 mm
Turning Circle
11.9 m

Interior

Head room front with panoramic roof
987 mm
Shoulder room rear
1 435 mm
Hip room front
1 422 mm
Head room rear with panoramic roof
979 mm
Leg room front
1 038 mm
Hip room rear
1 435 mm
Shoulder room front
1 465 mm
Leg room rear
940 mm

Storage - 6 Seats

Cargo floor width between wheel housing
1 130 mm
Third seatback to tailgate top of third seatback
335 mm
First seatback to tailgate - top of first seatback
1 903 mm
Cargo capacity - third row up
244 l
Cargo capacity - second row up
649 l
Cargo capacity - rear row(s) folded
1 165 l
Cargo capacity (max) - third row up
298 l
Cargo capacity (max) - second row up
976 l
Cargo capacity (max) - rear row(s) folded
1 976 l

Storage - 7 Seats

Cargo floor width between wheel housing
1 130 mm
Third seatback to tailgate top of third seatback
335 mm
First seatback to tailgate - top of first seatback
1 903 mm
Cargo capacity - third row up
244 l
Cargo capacity - second row up
650 l
Cargo capacity - rear row(s) folded
1 130 l
Cargo capacity (max) - third row up
298 l
Cargo capacity (max) - second row up
977 l
Cargo capacity (max) - rear row(s) folded
1 941 l

Track width may differ depending on wheel size.

Features

Category

  • Not included

  • Optional

  • Included

Charging

Portable charger, 7m (120/240V)

      Climate

      Afterrun parking climate

          Air purifier and remote cabin pre-cleaning

              Electric cabin heater and cooler

                  Four-zone climate system

                      Heated steering wheel

                          Heated windscreen

                              Humidity sensor

                                  Rear door sun curtains

                                      Third row air conditioning

                                          Wiper blades with integrated washers

                                              Drivers support

                                              11.2-inch centre display

                                                  12.3-inch driver display

                                                      360° camera

                                                          Active air suspension

                                                              Adaptive cruise control

                                                                  Adaptive power steering

                                                                      Auto-dimmed rear view mirrors

                                                                          BLIS™ (Blind Spot Information System)

                                                                              Comfort chassis with FSD damper technology

                                                                                  Cross traffic alert with low speed auto brake

                                                                                      Digital owners manual

                                                                                          Head-up display

                                                                                              Headlight cleaning

                                                                                                  Illuminated vanity mirrors

                                                                                                      Intersection autobrake

                                                                                                          Lane Keeping Aid

                                                                                                              Oncoming Lane Mitigation

                                                                                                                  Park assist, front, rear and sides

                                                                                                                      Pilot Assist

                                                                                                                          Power retractable door mirrors

                                                                                                                              Rain sensor

                                                                                                                                  Rear Collision Warning

                                                                                                                                      Road Sign Information

                                                                                                                                          Slippery road alert

                                                                                                                                              Volvo Assistance

                                                                                                                                                  Exterior

                                                                                                                                                  21-inch 5-multi spoke black diamond cut

                                                                                                                                                      22-inch 7-double spoke glossy black diamond cut

                                                                                                                                                          Bright aluminum trim around the side windows

                                                                                                                                                              Door mirror covers, colour coordinated

                                                                                                                                                                  Door mirror covers, high-gloss black

                                                                                                                                                                      Front grille with chrome frame and chrome inserts

                                                                                                                                                                          Front grille with high-gloss black frame and matt black inserts

                                                                                                                                                                              High-gloss black side window trim

                                                                                                                                                                                  Mud flaps, front

                                                                                                                                                                                      Panoramic roof

                                                                                                                                                                                          Protective cap kit, Matt Tech Grey

                                                                                                                                                                                              Roof rails, bright aluminum

                                                                                                                                                                                                  Roof rails, glossy black

                                                                                                                                                                                                      Tinted rear windows

                                                                                                                                                                                                          Interior

                                                                                                                                                                                                          Blond headlining

                                                                                                                                                                                                              Brown Ash decor

                                                                                                                                                                                                                  Charcoal headlining

                                                                                                                                                                                                                      Crystal gear shift by Orrefors®

                                                                                                                                                                                                                          Grey Ash decor

                                                                                                                                                                                                                              Illuminated sill moulding

                                                                                                                                                                                                                                  Interior illumination, high level

                                                                                                                                                                                                                                      Light Ash decor

                                                                                                                                                                                                                                          Navy Herringbone Weave textile upholstery

                                                                                                                                                                                                                                              Nubuck textile headlining

                                                                                                                                                                                                                                                  Rear centre armrest

                                                                                                                                                                                                                                                      Rear centre armrest

                                                                                                                                                                                                                                                          Remote key

                                                                                                                                                                                                                                                              Tailored dashboard and door top panels

                                                                                                                                                                                                                                                                  Tailored sport steering wheel, Charcoal

                                                                                                                                                                                                                                                                      Textile interior cabin floor mats

                                                                                                                                                                                                                                                                          Textile mats, third row

                                                                                                                                                                                                                                                                              Ventilated nappa leather upholstery

                                                                                                                                                                                                                                                                                  Pack & Load

                                                                                                                                                                                                                                                                                  Keyless entry with hands-free power tailgate

                                                                                                                                                                                                                                                                                      Power outlet, trunk

                                                                                                                                                                                                                                                                                          Tailgate scuff plate, stainless steel

                                                                                                                                                                                                                                                                                              Trailer lamp control

                                                                                                                                                                                                                                                                                                  Performance

                                                                                                                                                                                                                                                                                                  8-speed Geartronic™ automatic

                                                                                                                                                                                                                                                                                                      Hill Descent Control

                                                                                                                                                                                                                                                                                                          Hill Start Assist

                                                                                                                                                                                                                                                                                                              Start/Stop technology

                                                                                                                                                                                                                                                                                                                  Safety & Security

                                                                                                                                                                                                                                                                                                                  Alarm

                                                                                                                                                                                                                                                                                                                      Body-coloured door handles with ground lighting

                                                                                                                                                                                                                                                                                                                          Central locking controls, front and rear doors

                                                                                                                                                                                                                                                                                                                              Double locking

                                                                                                                                                                                                                                                                                                                                  Hidden storage

                                                                                                                                                                                                                                                                                                                                      HomeLink®

                                                                                                                                                                                                                                                                                                                                          Inflatable Curtain

                                                                                                                                                                                                                                                                                                                                              Integrated booster cushion

                                                                                                                                                                                                                                                                                                                                                  Intelligent Driver Information System (IDIS)

                                                                                                                                                                                                                                                                                                                                                      ISOFIX mounting points, rear seat

                                                                                                                                                                                                                                                                                                                                                          Knee airbag, driver side

                                                                                                                                                                                                                                                                                                                                                              Occupant Weight Sensor

                                                                                                                                                                                                                                                                                                                                                                  Power child safety lock

                                                                                                                                                                                                                                                                                                                                                                      Safety belts

                                                                                                                                                                                                                                                                                                                                                                          Side impact protection

                                                                                                                                                                                                                                                                                                                                                                              Temporary mobility kit

                                                                                                                                                                                                                                                                                                                                                                                  Whiplash injury protection

                                                                                                                                                                                                                                                                                                                                                                                      Seats

                                                                                                                                                                                                                                                                                                                                                                                      6 seats

                                                                                                                                                                                                                                                                                                                                                                                          7 seats

                                                                                                                                                                                                                                                                                                                                                                                              Comfort front seats

                                                                                                                                                                                                                                                                                                                                                                                                  Front seat massage

                                                                                                                                                                                                                                                                                                                                                                                                      Front seat ventilation

                                                                                                                                                                                                                                                                                                                                                                                                          Heated front seats

                                                                                                                                                                                                                                                                                                                                                                                                              Heated rear seats

                                                                                                                                                                                                                                                                                                                                                                                                                  Mechanical release second seat row

                                                                                                                                                                                                                                                                                                                                                                                                                      Power 4-way lumbar support

                                                                                                                                                                                                                                                                                                                                                                                                                          Power cushion extension, driver

                                                                                                                                                                                                                                                                                                                                                                                                                              Power driver seat with memory

                                                                                                                                                                                                                                                                                                                                                                                                                                  Power folding outer rear head restraints, second row

                                                                                                                                                                                                                                                                                                                                                                                                                                      Power passenger seat

                                                                                                                                                                                                                                                                                                                                                                                                                                          Power passenger seat with memory

                                                                                                                                                                                                                                                                                                                                                                                                                                              Power side bolsters

                                                                                                                                                                                                                                                                                                                                                                                                                                                  Tech & Sound

                                                                                                                                                                                                                                                                                                                                                                                                                                                  Air-ventilated subwoofer

                                                                                                                                                                                                                                                                                                                                                                                                                                                      Apple CarPlay and Android Auto

                                                                                                                                                                                                                                                                                                                                                                                                                                                          Bluetooth® connection

                                                                                                                                                                                                                                                                                                                                                                                                                                                              Bowers & Wilkins High Fidelity audio system

                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Google built-in

                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Harman Kardon Premium Sound

                                                                                                                                                                                                                                                                                                                                                                                                                                                                          SiriusXM Satellite Radio

                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Steering wheel remote control

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Volvo Cars app

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Wireless phone charging

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Shopping tools

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Compare models
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          View new car inventory
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          View special offers
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Book a test drive
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Contact your retailer

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Features and colours depicted may not be standard or available for all markets, package levels and powertrain options. European specifications shown. Google services are enabled through a digital services package that is included for four years. After this period, new terms and fees will apply if you choose to renew. Google, Google Maps and Google Play are trademarks of Google LLC.
