Explore XC90 specifications

Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.

Side view of the Volvo [ModelName + FuelType] with open hood, doors, and trunk in a white studio environment.

Platform

B6 AWD Mild hybrid (Gas)

Platform

Fuel Type
Gas
Driveline
AWD
Transmission
Automatic
Number of seats
6 - 7
Weight (Max Laden Mass)
2790 kg
Trailer max weight
2 250 kg
Roof load max weight
100 kg

Performance

Fuel Consumption (Combined)

Fuel Consumption (Combined)

The figures are based upon Natural Resources Canada (NRCan) approved test cycles. These outcomes are not guaranteed. Real-world fuel consumption varies depending on driving behaviour and other external factors. See https://fcr-ccc.nrcan-rncan.gc.ca/en for more information.

10.4 l/100km
Fuel Capacity
71 l
Max engine power (hp)

Max engine power (hp)

Power figures derive from estimates and calculations performed by Volvo Cars for the Volvo XC90. These outcomes are not guaranteed.

295 hp
Max torque
310 lb-ft
0-100 km/h

0-100 km/h

Acceleration time is based on the specified powertrain. Real-world results will vary depending on various factors, including weather and road conditions, tires and the car's weight.

6.7 s
Top speed
180 km/h

Car dimensions []

Exterior

Height
1 771 mm
Width (mirrors incl)
2 140 mm
Front track width
1 673 mm
Width
1 931 mm
Rear track width
1 675 mm
Vehicle length
4 953 mm
Wheel base
2 984 mm
Turning Circle
11.9 m

Interior

Head room front with panoramic roof
987 mm
Shoulder room rear
1 435 mm
Hip room front
1 422 mm
Head room rear with panoramic roof
979 mm
Leg room front
1 038 mm
Hip room rear
1 435 mm
Shoulder room front
1 465 mm
Leg room rear
940 mm

Storage - 6 Seats

Cargo floor width between wheel housing
1 130 mm
Third seatback to tailgate top of third seatback
335 mm
First seatback to tailgate - top of first seatback
1 903 mm
Cargo capacity - third row up
247 l
Cargo capacity - second row up
652 l
Cargo capacity - rear row(s) folded
1 174 l
Cargo capacity (max) - third row up
301 l
Cargo capacity (max) - second row up
979 l
Cargo capacity (max) - rear row(s) folded
1 985 l

Storage - 7 Seats

Cargo floor width between wheel housing
1 130 mm
Third seatback to tailgate top of third seatback
335 mm
First seatback to tailgate - top of first seatback
1 903 mm
Cargo capacity - third row up
247 l
Cargo capacity - second row up
653 l
Cargo capacity - rear row(s) folded
1 139 l
Cargo capacity (max) - third row up
301 l
Cargo capacity (max) - second row up
980 l
Cargo capacity (max) - rear row(s) folded
1 950 l

Track width may differ depending on wheel size.

Features

Category

  • Not included

  • Optional

  • Included

Climate

Afterrun parking climate

      Air purifier and remote cabin pre-cleaning

          Four-zone climate system

              Heated steering wheel

                  Heated windscreen

                      Humidity sensor

                          Rear door sun curtains

                              Third row air conditioning

                                  Wiper blades with integrated washers

                                      Drivers support

                                      11.2-inch centre display

                                          12.3-inch driver display

                                              360° camera

                                                  Active air suspension

                                                      Adaptive cruise control

                                                          Adaptive power steering

                                                              Auto-dimmed rear view mirrors

                                                                  BLIS™ (Blind Spot Information System)

                                                                      Comfort chassis with FSD damper technology

                                                                          Cross traffic alert with low speed auto brake

                                                                              Digital owners manual

                                                                                  Head-up display

                                                                                      Headlight cleaning

                                                                                          Illuminated vanity mirrors

                                                                                              Intersection autobrake

                                                                                                  Lane Keeping Aid

                                                                                                      Oncoming Lane Mitigation

                                                                                                          Park assist camera, rear

                                                                                                              Park assist, front, rear and sides

                                                                                                                  Park assist, rear and front

                                                                                                                      Pilot Assist

                                                                                                                          Power retractable door mirrors

                                                                                                                              Rain sensor

                                                                                                                                  Rear Collision Warning

                                                                                                                                      Road Sign Information

                                                                                                                                          Slippery road alert

                                                                                                                                              Volvo Assistance

                                                                                                                                                  Exterior

                                                                                                                                                  20-inch 5-multi spoke glossy black diamond cut

                                                                                                                                                      21-inch 5-multi spoke black diamond cut

                                                                                                                                                          22-inch 7-double spoke glossy black diamond cut

                                                                                                                                                              All-season Tires

                                                                                                                                                                  Bright aluminum trim around the side windows

                                                                                                                                                                      Door mirror covers, colour coordinated

                                                                                                                                                                          Door mirror covers, high-gloss black

                                                                                                                                                                              Front grille with chrome frame and chrome inserts

                                                                                                                                                                                  Front grille with high-gloss black frame and matt black inserts

                                                                                                                                                                                      High-gloss black side window trim

                                                                                                                                                                                          Mud flaps, front

                                                                                                                                                                                              Panoramic roof

                                                                                                                                                                                                  Protective cap kit, Black

                                                                                                                                                                                                      Protective cap kit, Matt Tech Grey

                                                                                                                                                                                                          Roof rails, bright aluminum

                                                                                                                                                                                                              Roof rails, glossy black

                                                                                                                                                                                                                  Tinted rear windows

                                                                                                                                                                                                                      Interior

                                                                                                                                                                                                                      Blond headlining

                                                                                                                                                                                                                          Brown Ash decor

                                                                                                                                                                                                                              Charcoal headlining

                                                                                                                                                                                                                                  Crystal gear shift by Orrefors®

                                                                                                                                                                                                                                      Grey Ash decor

                                                                                                                                                                                                                                          Illuminated sill moulding

                                                                                                                                                                                                                                              Interior illumination, high level

                                                                                                                                                                                                                                                  Light Ash decor

                                                                                                                                                                                                                                                      Navy Herringbone Weave textile upholstery

                                                                                                                                                                                                                                                          Nubuck textile headlining

                                                                                                                                                                                                                                                              Quilted Nordico upholstery

                                                                                                                                                                                                                                                                  Quilted Nordico upholstery

                                                                                                                                                                                                                                                                      Rear centre armrest

                                                                                                                                                                                                                                                                          Rear centre armrest

                                                                                                                                                                                                                                                                              Remote key

                                                                                                                                                                                                                                                                                  Remote key

                                                                                                                                                                                                                                                                                      Tailored dashboard and door top panels

                                                                                                                                                                                                                                                                                          Tailored leather steering wheel

                                                                                                                                                                                                                                                                                              Tailored sport steering wheel, Charcoal

                                                                                                                                                                                                                                                                                                  Textile interior cabin floor mats

                                                                                                                                                                                                                                                                                                      Textile mats, third row

                                                                                                                                                                                                                                                                                                          Ventilated nappa leather upholstery

                                                                                                                                                                                                                                                                                                              Pack & Load

                                                                                                                                                                                                                                                                                                              Keyless entry with hands-free power tailgate

                                                                                                                                                                                                                                                                                                                  Power outlet, trunk

                                                                                                                                                                                                                                                                                                                      Tailgate scuff plate, stainless steel

                                                                                                                                                                                                                                                                                                                          Trailer lamp control

                                                                                                                                                                                                                                                                                                                              Performance

                                                                                                                                                                                                                                                                                                                              8-speed Geartronic™ automatic, AWD

                                                                                                                                                                                                                                                                                                                                  Hill Descent Control

                                                                                                                                                                                                                                                                                                                                      Hill Start Assist

                                                                                                                                                                                                                                                                                                                                          Start/Stop technology

                                                                                                                                                                                                                                                                                                                                              Safety & Security

                                                                                                                                                                                                                                                                                                                                              Alarm

                                                                                                                                                                                                                                                                                                                                                  Body-coloured door handles with ground lighting

                                                                                                                                                                                                                                                                                                                                                      Central locking controls, front and rear doors

                                                                                                                                                                                                                                                                                                                                                          Double locking

                                                                                                                                                                                                                                                                                                                                                              Hidden storage

                                                                                                                                                                                                                                                                                                                                                                  HomeLink®

                                                                                                                                                                                                                                                                                                                                                                      Inflatable Curtain

                                                                                                                                                                                                                                                                                                                                                                          Integrated booster cushion

                                                                                                                                                                                                                                                                                                                                                                              Intelligent Driver Information System (IDIS)

                                                                                                                                                                                                                                                                                                                                                                                  ISOFIX mounting points, rear seat

                                                                                                                                                                                                                                                                                                                                                                                      Knee airbag, driver side

                                                                                                                                                                                                                                                                                                                                                                                          Occupant Weight Sensor

                                                                                                                                                                                                                                                                                                                                                                                              Power child safety lock

                                                                                                                                                                                                                                                                                                                                                                                                  Safety belts

                                                                                                                                                                                                                                                                                                                                                                                                      Side impact protection

                                                                                                                                                                                                                                                                                                                                                                                                          Tempered side and rear windows

                                                                                                                                                                                                                                                                                                                                                                                                              Temporary spare wheel

                                                                                                                                                                                                                                                                                                                                                                                                                  Whiplash injury protection

                                                                                                                                                                                                                                                                                                                                                                                                                      Seats

                                                                                                                                                                                                                                                                                                                                                                                                                      6 seats

                                                                                                                                                                                                                                                                                                                                                                                                                          7 seats

                                                                                                                                                                                                                                                                                                                                                                                                                              Comfort front seats

                                                                                                                                                                                                                                                                                                                                                                                                                                  Front seat massage

                                                                                                                                                                                                                                                                                                                                                                                                                                      Front seat ventilation

                                                                                                                                                                                                                                                                                                                                                                                                                                          Heated front seats

                                                                                                                                                                                                                                                                                                                                                                                                                                              Heated rear seats

                                                                                                                                                                                                                                                                                                                                                                                                                                                  Mechanical release second seat row

                                                                                                                                                                                                                                                                                                                                                                                                                                                      Power 2-way lumbar support

                                                                                                                                                                                                                                                                                                                                                                                                                                                          Power 4-way lumbar support

                                                                                                                                                                                                                                                                                                                                                                                                                                                              Power cushion extension, driver

                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Power driver seat with memory

                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Power folding outer rear head restraints, second row

                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Power passenger seat

                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Power passenger seat with memory

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Power side bolsters

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Tech & Sound

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Air-ventilated subwoofer

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Android Auto

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Apple CarPlay

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Bluetooth® connection

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Bowers & Wilkins High Fidelity audio system

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Google built-in

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Harman Kardon Premium Sound

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  High Performance audio system

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      SiriusXM Satellite Radio

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          Steering wheel remote control

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Volvo Cars app

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Wireless phone charging
