Explore EX30 specifications

Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.

Side view of the fully electric Volvo EX30 with open hood, doors, and trunk.

Platform

Single Motor Extended Range

Platform

Fuel Type
Electric
Driveline
RWD
Transmission
Automatic
Number of seats
5
Weight (Running Order Mass)
1 850 kg
Trailer max weight
1 600 kg
Roof load max weight
75 kg

Performance

Electric Range
Up to 462 km
Electric energy consumption combined (NEDC)
17.5 kWh/100km
Power
200 kW / 272 hp
Max torque
343 Nm
0-100 km/h
5.3 s
Top speed
180 km/h

Charging

Battery energy (nominal)
69 kWh
Battery charging duration 0-100% (3-phase 16A)
8 h
Battery charging duration 10-80% (DC 175kW)
28 min

Twin Motor Performance



Fuel Type
Electric
Driveline
AWD
Transmission
Automatic
Number of seats
5
Weight (Running Order Mass)
1 960 kg
Trailer max weight
1 600 kg
Roof load max weight
75 kg



Electric Range
Up to 417 km
Electric energy consumption combined (NEDC)
19.1 kWh/100km
Power
315 kW / 428 hp
Max torque
543 Nm
0-100 km/h
3.7 s
Top speed
180 km/h



Battery energy (nominal)
69 kWh
Battery charging duration 0-100% (3-phase 16A)
8 h
Battery charging duration 10-80% (DC 175kW)
28 min

Features and upgrades

Equipment level

Category

  • Not included

  • Optional

  • Included

Will it fit?

See how these items fit in the boot
Thule Shine stroller
Golf bag
Dresser

Car dimensions

Exterior

Vehicle height at kerb weight with one person
1 550 mm
Width (mirrors incl)
2 032 mm
Front track width
1 590 mm
Width
1 838 mm
Width (mirrors folded)
1 940 mm
Rear track width
1 595 mm
Vehicle length
4 233 mm
Wheel base
2 650 mm
Turning circle
11 m

Interior

Max head room front
1 058 mm
Shoulder room rear
1 346 mm
Hip room front
1 379 mm
Head room rear
974 mm
Leg room front
1 063 mm
Hip room rear
1 175 mm
Shoulder room front
1 400 mm
Leg room rear
821 mm

Storage

Cargo floor width between wheel housing
994 mm
Second seatback to tailgate - top of second seatback
566 mm
First seatback to tailgate - top of first seatback
1 355 mm
Cargo capacity (max) - second row up
400 l
Cargo capacity (max) - rows folded
1 000 l
Cargo capacity (front)
7 l

Overseas model shown. Information and photographs on this website may include overseas models and features not available in Australia.
Please confirm exact specifications, features and availability with your local Volvo retailer.
